y type ball valve
-size：dn50~dn300
-connection standard：pn10/16, ansi150, din16, jis10k, 16k
-working temperature：-15~300℃
-working pressure：pn10~pn25
-body：wcb、ss304、ss316、ss316l
-disc：wcb、ss304、ss316、ss316l
-seal：hard metal seal
-medium：powder
-operating：pneumatic、electric
ordering hotline：021-54150349
- product introduction
- product parameters
y-type three-way ball valve has two types of body structure, 120 degree and 135 degree per each channel. y-type three-way ball valve has flat flow passage, small fluid resistance and perfect flow capacity. when switching, the medium is not detained and will not cause secondary pollution. this valve could realize automatic control by adding the electric actuator and pneumatic actuator.
