nitrogen seal regulating valve
size：dn15~dn200
pressure：pn16~pn64
flange standard：gb/t9113，jb/t79
connection：flange(ff, rf, rtj)、welding(sw, bw)、thread(adopt for the valve size <1”)
gland type：hold-down bolt type
seal type：v type ptfe、polytetrafluoroethylene asbestos filler, asbestos textile filler, graphite filler
ordering hotline：021-54150349
- product introduction
- product parameters
there is one trim and one seat within the single seat regulating valve,，the advantage is the small leakage, with the big unbalanced force，its allowable differential pressure is smaller than that of two-seat valve. it is better to equip with valve positioned for the high pressure difference and large caliber, the valve with nominal diameter (> 25mm) is of double guiding structure. it can be opened or closed by changing the connecting position between the stem and the spool.
